Comparisons
Kato Unitrack vs Bachmann E-Z Track: N Scale System Guide

Choose between KATO Unitrack and Bachmann E-Z Track by the pieces your N-scale plan needs. The featured photo is KATO item 20-172 only; the linked Bachmann section is a separate example.
Compare exact N-scale curve sections
The KATO 20-172 is listed as four N-scale curve sections, each with a 183 mm (7 inch) radius and 45-degree arc. The Bachmann 44001 is N scale (1:160), with concrete ties and an 11.25-inch curve radius. Those examples have different radii, so they are not a like-for-like geometry test.
KATO also lists the N-scale 20-183 double curve as R315/282 mm. Its 282 mm inner curve is closer to 11.25 inches (285.75 mm), but still is not the same stated radius. Check the exact section plan and manufacturer dimensions before treating two curves as interchangeable.
Plan the whole track system
- Scale and smallest radius: Confirm every locomotive and car can handle the selected curve. Check the track plan's inside and outside radii.
- Turnouts and route: Sketch sidings, yards and station tracks before ordering. Confirm the system offers the turnout geometry and lengths the plan needs.
- Connections: Check the rail joiners and roadbed ends on the actual pieces. Do not assume the two brands connect directly; verify any transition track or adapter.
- Power: Plan feeder locations and any insulated sections around the layout. KATO's UniJoiners can be replaced with wired or insulated joiners; check the instructions for the chosen system.
- Table footprint: Include roadbed width, structures and hand access outside the rails, not just the curve radius.
Choose for your layout
Compare the same scale, radius, arc, section count and turnout path when evaluating individual pieces. Then check power connections, roadbed appearance and expansion parts across the full layout. A product page establishes the specifications it states; it does not establish that every component in a system fits every railroad plan.
